技术数据
氧化铝

				CAPA95	CAPA97	CAPA99	CAPA995	CAPA997	CAPA998
			UNITS	95瓷	97瓷	99瓷	995瓷	997瓷	998瓷
密度			G/CM³	3.7	3.8	3.88	3.9	3.9	3.9
吸收率				0	0	0	0	0	0
颜色				白色	白色	米白色	象牙色	象牙色	象牙色
特性综述				适用性广耐磨性绝缘性介电强度低介电损耗
机械性能	维氏强度		GPa	13.0	14.0	15.5	16.0	17.2	17.2
	弯曲强度		MPa	320	350	350	370	380	380
	抗压强度		MPa	1960	2200	2250	2300	2350	2350
	杨氏模量		GPa	310	320	350	360	360	360
	泊松比		-	0.23	0.23	0.23	0.23	0.23	0.23
	断裂韧性		Mpa・m^1/2	3 - 4	3 - 4	3 - 4	4 - 5	4 - 5	4 - 5
热性能	热膨胀系数	20-800℃	1x10^-6/℃	7.2	7.2	7.3	7.3	7.3	7.2
	导热性	20℃	W/(m.K)	22	24	27	28	30	30
	最高使用温度		℃	1600	1600	1650	1700	1700	1700
	比热容		J/(g.K)	0.78	0.78	0.79	0.78	0.79	0.78
	耐热冲击性		℃	200	200	200	200	200	200
电性能	介电强度		kV/mm	15	15	15	15	15	15
	体积电阻率	20℃	Ω.cm	>10¹⁴	>10¹⁴	>10¹⁴	>10¹⁴	>10¹⁴	>10¹⁴
	体积电阻率	300℃	Ω.cm	10¹²	10¹²	10¹²	10¹²	10¹²	1012
*以上数值可能会因产品配置和制造过程而有所不同，仅供参考。

				CAPA-Y-ZrO
			UNITS	YTTRIA-STABLIZED ZIRCONIA
Density			G/CM³	6
Water Absorption				0
Color				White
Main Characteristics				Toughness Mechanical Strength High Heat Resistance Corrosion Resistance
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	12.7
	Flexural Strength	MOR(20℃)	MPa	1000
	Compressive Strength		MPa	5000
	Young's Modulus of Elasticity		GPa	220
	Possion Ratio		-	0.31
	Fracture Toughness		Mpa・m^1/2	4 - 5
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6 /℃	11.0
	Thermal Conductivity	20℃	W/(m.K)	3
	Specific Heat		J/(g.K)	0.46
	Heat Shock Resistance(Put in water)		℃	-
Electrical Characteristics	Dielectric Strength		kV/mm	11.0
	Volume Resistivity	20℃	Ω.cm	10¹³
	Volume Resistivity	300℃	Ω.cm	10⁶
*The values are typical material properties and may vary according to products configuration and manufacturing process.

				CAPA-Mg-ZrO
			UNITS	MAGNESIUM-STABLIZED ZIRCONIA
Density			G/CM3	5.8
Water Absorption				0
Color				Beige
Main Characteristics
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	12.0
	Flexural Strength	MOR(20℃)	MPa	545
	Compressive Strength		MPa	2400
	Young's Modulus of Elasticity		GPa
	Possion Ratio		-
	Fracture Toughness		Mpa・m^1/2	6.0
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6/℃	10.2
	Thermal Conductivity	20℃	W/(m.K)	2.2
	Specific Heat		J/(g.K)
	Heat Shock Resistance(Put in water)		℃	-
Electrical Characteristics	Dielectric Strength		kV/mm
	Volume Resistivity	20℃	Ω.cm	10¹⁴
	Volume Resistivity	300℃	Ω.cm
*The values are typical material properties and may vary according to products configuration and manufacturing process.

				CAPA-SSiC
			UNITS	SILICON CARBIDE SSIC
Density			G/CM³	3.2
Water Absorption				0
Color				Black
Main Characteristics				Hardness Wear Resistant Mechanical strength Light Weight
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	23
	Flexural Strength	MOR(20℃)	MPa	540
	Compressive Strength		MPa	-
	Young's Modulus of Elasticity		GPa	440
	Possion Ratio		-	0.17
	Fracture Toughness		Mpa・m^1/2	4 - 5
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6 /℃	3.7 - 4.4
	Thermal Conductivity	20℃	W/(m.K)	60
	Specific Heat		J/(g.K)	0.67
	Heat Shock Resistance(Put in water)		℃	-
Electrical Characteristics	Dielectric Strength		kV/mm	-
	Volume Resistivity	20℃	Ω.cm	10⁵
	Volume Resistivity	300℃	Ω.cm	10⁴
*The values are typical material properties and may vary according to products configuration and manufacturing process.

				CAPA-RBSiC
			UNITS	REACTION BONDED SILICON CARBIDE
Density			G/CM³	3.2
Water Absorption				0
Color				Black
Main Characteristics				Hardness Wear Resistant Mechanical strength Light Weight
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	22
	Flexural Strength	MOR(20℃)	MPa	450
	Compressive Strength		MPa	-
	Young's Modulus of Elasticity		GPa	430
	Possion Ratio		-	0.16
	Fracture Toughness		Mpa・m^1/2	4 - 5
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6 /℃	3.7 - 4.4
	Thermal Conductivity	20℃	W/(m.K)	60
	Specific Heat		J/(g.K)	0.67
	Heat Shock Resistance(Put in water)		℃	-
Electrical Characteristics	Dielectric Strength		kV/mm	-
	Volume Resistivity	20℃	Ω.cm
	Volume Resistivity	300℃	Ω.cm
*The values are typical material properties and may vary according to products configuration and manufacturing process.

				CAPA-SIN
			UNITS	SILICON NITRIDE
Density			G/CM³	3.2
Water Absorption				0
Color				Black
Main Characteristics				High toughness Thermal shock resistant Tight tolerances
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	13.9
	Flexural Strength	MOR(20℃)	MPa	580
	Compressive Strength		MPa	-
	Young's Modulus of Elasticity		GPa	290
	Possion Ratio		-	0.28
	Fracture Toughness		Mpa・m^1/2	4 - 5
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6 /℃	2.4 - 3.2
	Thermal Conductivity	20℃	W/(m.K)	25
	Specific Heat		J/(g.K)	0.64
	Heat Shock Resistance(Put in water)		℃	-
Electrical Characteristics	Dielectric Strength		kV/mm	12
	Volume Resistivity	20℃	Ω.cm	>10¹⁴
	Volume Resistivity	300℃	Ω.cm	10¹²
*The values are typical material properties and may vary according to products configuration and manufacturing process.

				CAPA-AlN
			UNITS	SILICON NITRIDE
Density			G/CM³	3.2
Water Absorption				0
Color				Gray
Main Characteristics				Thermally stable Electrical resistivity
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	10.4
	Flexural Strength	MOR(20℃)	MPa	350
	Compressive Strength		MPa	-
	Young's Modulus of Elasticity		GPa	310
	Possion Ratio		-	0.24
	Fracture Toughness		Mpa・m^1/2	-
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6 /℃	4.6
	Thermal Conductivity	20℃	W/(m.K)	140
	Specific Heat		J/(g.K)	0.738
	Heat Shock Resistance(Put in water)		℃	-
Electrical Characteristics	Dielectric Strength		kV/mm	25
	Volume Resistivity	20℃	Ω.cm	10¹²
	Volume Resistivity	300℃	Ω.cm
*The values are typical material properties and may vary according to products configuration and manufacturing process.

				CAPA-STE
			UNITS	STEATITE
Density			G/CM³	2.8
Water Absorption				0
Color				White
Main Characteristics				Excellent dielectric strength Good dielectric loss
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	5.8
	Flexural Strength	MOR(20℃)	MPa	140 - 160
	Compressive Strength		MPa	-
	Young's Modulus of Elasticity		GPa	120
	Possion Ratio		-	0.22
	Fracture Toughness		Mpa・m^1/2	-
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6 /℃	7.7 - 10.0
	Thermal Conductivity	20℃	W/(m.K)	2.0 - 3.0
	Specific Heat		J/(g.K)
	Heat Shock Resistance(Put in water)		℃	250
Electrical Characteristics	Dielectric Strength		kV/mm
	Volume Resistivity	20℃	Ω.cm
	Volume Resistivity	300℃	Ω.cm
*The values are typical material properties and may vary according to products configuration and manufacturing process.

				CAPA-CODI
			UNITS	CORDIERITE
Density			G/CM³	2.3
Water Absorption				0
Color				Gray
Main Characteristics				Excellent thermal shock resistance Heat resistance Low thermal expansion
Mechanical Characteristics	Vicker Hardness (Load 500g)		GPa	-
	Flexural Strength	MOR(20℃)	MPa	30
	Compressive Strength		MPa	-
	Young's Modulus of Elasticity		GPa	140
	Possion Ratio		-	0.31
	Fracture Toughness		Mpa・m^1/2	-
Thermal Characteristics	Coefficient of Linear Thermal Expansion	40-800℃	1x10^-6 /℃	<0.2(22-23℃）
	Thermal Conductivity	20℃	W/(m.K)	2.0 - 3.0
	Specific Heat		J/(g.K)	0.71
	Heat Shock Resistance(Put in water)		℃	1000
Electrical Characteristics	Dielectric Strength		kV/mm	19.1
	Volume Resistivity	20℃	Ω.cm	>10¹⁴
	Volume Resistivity	300℃	Ω.cm	10¹²
*The values are typical material properties and may vary according to products configuration and manufacturing process.
